Four Wheel Camper Install Eye-Bolt Measurements

Break down of typical eye bolt locations by model for proper installation

Eye-Bolt Install Measurements

Measure the tie down brackets on the camper first! Then check for obstacles under the truck bed (gas lines, brake lines, bed frame…etc.)

Grandby Model:

  • Original Roll Over Couch Floor Plan: (front eye bolts 12” back from the front of the truck bed / rear eye bolts 76” back from the front of the truck bed).

  • Side Dinette Seating Floor Plan: (front eye bolts 12” back from the front of the truck bed / rear eye bolts 76” back from the front of the truck bed).

  • New Front Dinette Seating Floor Plan: (front eye bolts 11” back from the front of the truck bed / rear eye bolts 74” back from the front of the truck bed).

Hawk Model:

  • Original Roll Over Couch Floor Plan: (front eye bolts 12” back from the front of the truck bed / rear eye bolts 61” back from the front of the truck bed).

  • Side Dinette Seating Floor Plan: (front eye bolts 12” back from the front of the truck bed / rear eye bolts 61” back from the front of the truck bed).

  • The newer Front Dinette Seating Floor Plan: (front eye bolts 11” back from the front of the truck bed / rear eye bolts 58” back from the front of the truck bed).

Raven Model:

  • Roll Over Couch Floor Plan: (front eye bolts 12” back from the front of the truck bed / rear eye bolts 51” back from the front of the truck bed).

Fleet Model:

  • Original Roll Over Couch Floor Plan: (front eye bolts 12” back from the front of the truck bed / rear eye bolts 61” back from the front of the truck bed).

  • Side Dinette Seating Floor Plan: (front eye bolts 12” back from the front of the truck bed / rear eye bolts 61” back from the front of the truck bed).

  • The newer Front Dinette Seating Floor Plan: (front eye bolts 10” back from the front of the truck bed / rear eye bolts 57” back from the front of the truck bed).

Swift Model:

  • Original Roll Over Couch Floor Plan:   Most ALL Swift Model camper installations require the camper to either be “bolted down” to the truck bed, or you can sometimes use the “External Camper Tie” downs if Tork-Lift makes a kit for their truck

The only exception: is if the customer has a 2005 – 2017 Toyota Tacoma standard cab, access cab, or the Crew Cab with the LONG 6.0’ truck bed. If the customer is putting the Swift Model on the 2005 – 2017 Toyota Tacoma truck that has the LONGER 6.0’ bed, they can use the custom made FWC black steel Tacoma Bed Bars we sell for tying the camper down on the truck.
